🏆 High-Performance $\mathbf{SMT}$ $\mathbf{Target}$ $\mathbf{Disc}$ (Round Contact Pad)

💯 5$0,000$ Cycle Lifetime, Cost-Saving Alternative to $\mathbf{Mill}\text{–}\mathbf{Max}$ $1578$

Core Value: Solving $\mathbf{Pogo}$ $\mathbf{Pin}$ Mating System’s Three Major Pain Points

[Insert $\varphi 3.0\text{mm}$ Target Disc Product Photo Here]

Are your devices suffering from PCB gold finger wear or unstable connection due to frequent mating cycles or vibration? Jiatel’s high-performance $\mathbf{SMT}$ Contact Pads are engineered to eliminate these issues, offering performance significantly superior to standard $\text{PCB}$ pads.

Key Features Overview

• ⚡ Ultra-High Durability ($\mathbf{PCB}$ Protection): Offers an exceptionally long service life of 50,000+ cycles, effectively shielding expensive $\text{PCB}$ gold fingers from direct wear caused by $\text{Pogo Pin}$ tips.
• 🔋 Excellent Current Carrying Capacity: Rated current range from $1\text{A}$ up to a maximum of $6\text{A}$, perfectly meeting the demands of modern fast charging and high-power transmission applications.
• 🛡️ Extremely Reliable Signal Transfer: Made from premium gold-plated copper alloy, ensuring ultra-low contact resistance ($\le 0.15\text{m}\mathbf{\Omega }$), suitable for all high-reliability signal and power transfer scenarios.
• 📏 Critical Dimensioning: This product features the $\varphi 3.0\times 0.5\text{mm}$ specification with a standard flat bottom design, fully supporting Automated Surface Mount Technology ($\text{SMT}$) processes, greatly simplifying assembly.

Technical Specifications and Performance Comparison

[Insert $\varphi 3.0\text{mm}$ Target Disc Mechanical Drawing, Annotating Key Dimensions]

Our $\mathbf{Target}$ $\mathbf{Disc}$ is not just a cost-effective alternative to $\text{Mill-Max}$ $1578$; we also guarantee high-standard quality across critical performance indicators.

Feature	Jiatel SMT Target Disc	Standard $\text{PCB}$ Contact Pad	Key Advantage
Mating Cycles (Durability)	$50,000$ $\mathbf{Min}$	$\sim 1,000$ (Depending on gold thickness)	Ultra-Long Lifespan / $\mathbf{PCB}$ $\mathbf{Protection}$
Max Current	$\text{3A}$	$\sim 3\text{A}$	High Current $6\text{A}$
Contact Resistance ($\mathbf{R}$)	$\le 0.15\text{m}\mathbf{\Omega }$	$\le 0.2\text{m}\Omega$	Ultra-Low Contact Resistance / High Reliability
Dimensions	$\varphi 3.0\times 0.5\text{mm}$	Varied	Clear Spec, Easy Selection
Material	$\text{BeCu}$ / Phosphor Bronze	Brass / Copper	Better elasticity, high fatigue resistance
Process	Stamping + Gold Plating	Stamping + Gold Plating	SMT Compatible

Commercial Advantages: Supply Chain Security & Cost Efficiency

By choosing us as your connector supplier, you gain supply chain flexibility and significant cost reduction potential.

1. High Value $\mathbf{Mill}\text{–}\mathbf{Max}$ Alternative

We offer competitive pricing, leading to significant cost savings for high-volume projects. Through optimized design and production, we ensure $\mathbf{Pogo}$ $\mathbf{Pin}$ $\mathbf{Pad}$ cost reduction without compromising quality.

2. Fast Sampling and Custom Design

We possess strong capabilities in non-standard customization, allowing us to design the product based on your specific size, height, or current requirements.

• Quick Response: Standard products are available in stock.
• Sampling Lead Time: $8\sim 10$ $\mathbf{Day}$ Fast Sampling.
• Tooling Cost: Low $\mathbf{NRE}$ Fees (Non-Recurring Engineering)

3. Ideal Secondary Source

As a reliable manufacturer specializing in high-precision connectors, we can serve as the ideal alternative and secondary source to your existing Western brands (like $\text{Mill-Max}$), ensuring your supply chain remains resilient and unrestricted.

Contact Us Today

We are ready to provide free samples or proceed with non-standard customization based on your project needs.

📞 Contact our sales team now to get a quote and technical datasheet for the $\varphi 3.0\text{mm}$ High-Durability Target Disc.

We look forward to supporting your high-reliability connection systems.
