1*5 female Header

1×5 Female Header Socket

Operating Temperature

-40℃ ~ +105℃
Download Technical Datasheet

Industrial-Grade 5 Pin Female Header Socket – 0.1” Spacing, Gold-Plated Contacts

1*5 female Header drawing

Upgrade your PCB connectivity with our 1×5 Female Header Socket, engineered for superior performance in professional and DIY applications. This precision connector features:

Technical Specifications



  • Pitch: 0.1” (2.54mm) centerline spacing
  • Contact Material: Gold-plated phosphor bronze for corrosion resistance
  • Mounting: Through-hole solder tails for secure PCB installation
  • Housing: Flame-retardant PA6T (UL 94 V-0), operating temperature: -40°C to +105°C
  • Physical Dimensions: 0.335” (8.5mm) body height

Key Features



  • Reliable Performance: 1A current rating, 1000V AC voltage resistance
  • Perfect Fit: Mates with 0.025” square post headers
  • Versatile Use: Ideal for prototyping, industrial automation, automotive systems, and medical devices

Why Choose Us?



  • Bulk Discounts: Save on large quantities for production needs
  • Free Samples: Test compatibility before purchase
  • Quality Assurance: RoHS compliant with 90-day satisfaction guarantee

Need a Custom Solution?
