Description: Alternative of Mill-Max 5257 Wire Wrap Terminal Pin
|
Mounting Feature: Press-Fit into a Non-Plated Through Hole (NPTH) or Insulator Product Family:Printed Circuit Board (PCB) Pin Packaging: Packaged in Bulk RoHS : Yes Product Lifecycle : Active MaterialsShell Material : Brass Alloy Shell Plating : 10 μ” Gold over Nickel |
Technical SpecsOperating Temperature Range : – 55/+125° C Current Rating : Application Specific |
| Part No. | Shell Plating | ROHS |
|---|---|---|
|
5275-1-05-15-00-00-01-0
|
15: – 10 μ” Gold over Nickel | Yes |
| 5275-1-05-01-00-00-01-0 | 01: – 200 – 300 μ” Tin/Lead over Nickel | No |
| 5275-1-05-21-00-00-01-0 | 21: – 20 μ” Gold over Nickel | Yes |
| 5275-1-05-80-00-00-01-0 | 80: – 200 – 300 μ” Tin (matte finish) over Nickel | Yes |
| 5275-2-05-01-00-00-01-0 | 01: – 200 – 300 μ” Tin/Lead over Nickel | No |
| 5275-2-05-15-00-00-01-0 | 15: – 10 μ” Gold over Nickel | Yes |
| 5275-2-05-21-00-00-01-0 | 21: – 20 μ” Gold over Nickel | Yes |
| 5275-2-05-80-00-00-01-0 | 80: – 200 – 300 μ” Tin (matte finish) over Nickel | Yes |
| 5275-3-05-01-00-00-01-0 | 01: – 200 – 300 μ” Tin/Lead over Nickel | No |
| 5275-3-05-15-00-00-01-0 | 15: – 10 μ” Gold over Nickel | Yes |
