OBD Connector
Professional OBD2 (J1962) Interconnect Solutions
1. Integrated Custom OBD2 Male & Female Connector Solutions
Jiatel is a premier manufacturer of custom OBD2 male and female connectors, providing end-to-end interconnect solutions for the automotive industry. Whether you are developing a professional diagnostic tool requiring rugged J1962 male plugs or a telematics module needing high-precision PCB mount female sockets, we ensure 100% compatibility and IATF 16949 quality standards.
Jiatel is an IATF 16949 certified manufacturer specializing in high-retention OBD2 connectors. We provide rugged J1962 interfaces designed for telematics and automotive diagnostics, ensuring zero signal dropout in high-vibration environments.
Request a Custom Pinout QuoteBrowse OBD Wiring Harnesses
Why Jiatel for Automotive Projects?
- Zero-Failure Design: Anti-pin push-out technology ensures stable “Request & Response” data flow.
- Fast Customization: 12-hour DFM analysis for overmolded OBD cables and custom pinouts.
- Premium Materials: Using PA66+GF for plugs and PA9T/LCP for PCB sockets to withstand 260°C reflow.
2. Engineering Expertise in Custom OBD Interconnects
- Full Customization: We support custom pin loading, unique housing geometries, and proprietary branding (logo embossing).
- Advanced Materials: We utilize PA9T and LCP for SMT components to survive 260°C reflow, and PA66+GF for overmolded plugs to ensure maximum impact resistance.
- Superior Contact Plating: Options from standard 3u” to 30u” Gold plating to maintain zero-loss data transmission in CAN Bus networks.
3. Complete Solution Comparison
| Component Type | Key Engineering Feature | Application Focus |
|---|---|---|
| OBD2 Male Plug | Anti-Pin Push-out & Overmolding | Diagnostic Cables, Scan Tools |
| OBD2 Female Socket | High-Temp PA9T & Positioning Posts | Telematics, Dash Cams, ECU Interface |
4. Rapid Prototyping & DFM Support
Time-to-market is critical in automotive electronics. Jiatel provides 12-hour DFM (Design for Manufacturing) reviews of your STEP/IGS files. We specialize in overmolded cable assemblies, delivering prototypes in 8-10 days and mass production within 2-3 weeks.
Ready to streamline your automotive interconnects? Jiatel offers the complete male-to-female ecosystem for your next project. Inquire with our Technical Team for a specialized quote.
Specifications & Lead Time
| Compliance | Lead Time | MOQ |
|---|---|---|
| IATF 16949 / RoHS | 2-3 Weeks | Flexible for Prototypes |
Need 2D Footprint Specs? Our engineering team provides 2D drawings and DFM feedback within 12 hours. Advanced CAD data is released only for qualified production programs. Inquire Now
Related Search Keywords: OBD-II Connector, J1962 Interface, Vehicle Diagnostic Connector, Automotive OBD Plug, Custom OBD Cable, Overmolded OBD Connector, Male OBD2 Plug.
